At NAB 2017, Canon showed off C-Log for their 5D Mark IV DSLR. Now, this is a paid update to the Canon 5D Mark IV with a cost of $99.00. Owners will also need to send in their Canon 5D Mark IV to the manufacturer to install the update. For my dynamic range, around 12 stops, this seems like not a huge ordeal. In my opinion, it’s cool to see Canon put a feature in the 5D Mark IV that was originally in a much more expensive video camera. In the video below, Canon takes the time to show the dynamic range benefit of C-log over the standard picture profile found in the camera.
https://vimeo.com/215046709
| Lens Mount |
Canon EF |
| Camera Format |
Full-Frame (1.0x Crop Factor) |
| Pixels |
Actual: 31.7 Megapixel
Effective: 30.4 Megapixel |
| Max Resolution |
30.4 MP: 6720 x 4480 |
| Aspect Ratio |
3:2 |
| Sensor Type / Size |
CMOS, 36 x 24 mm |
| File Formats |
Still Images: JPEG, RAW
Movies: MJPEG, MOV, MP4, MPEG-4 AVC/H.264
Audio: AAC, Linear PCM (Stereo) |
| Bit Depth |
14-Bit |
| Dust Reduction System |
Yes |
| Memory Card Type |
CompactFlash
SDXC
SDHC
SD |
| Viewfinder Type |
Pentaprism |
| Viewfinder Eye Point |
21.00 mm |
| Viewfinder Coverage |
100% |
| Viewfinder Magnification |
Approx. 0.71x |
| Diopter Adjustment |
-3 to +1 m |
| Display Screen |
3.2″ Rear Touchscreen LCD (1,620,000) |
| Screen Coverage |
100% |
| Diagonal Angle of View |
170.0° |
| ISO Sensitivity |
Auto, 100-32000 (Extended Mode: 50-102400) |
| Shutter |
Type: Electronic & Mechanical
Speed: 30 – 1/8000 Second , Bulb Mode |
| Remote Control |
TC-80N3, RS-80N3 (Optional) |
| Mirror Lock-Up |
Yes |
| Metering Method |
Evaluative Metering, Partial Metering, Spot Metering |
| Exposure Modes |
Modes: Aperture Priority, Auto, Manual, Programmed Auto, Shutter Priority
Metering Range: EV 0.0 – EV 20.0
Compensation: -5 EV to +5 EV (in 1/3 EV Steps) |
| Continuous Shooting |
Up to 7 fps at 30 MP for up to 21 frames in raw format
Up to 7 fps at 30 MP for unlimited frames in JPEG format |
| White Balance Modes |
Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten |
| Video Recording |
Yes, NTSC/PAL |
| File Size |
4096 x 2160p
1920 x 1080p
1280 x 720p |
| Video Format |
4096 x 2160p at 23.98, 24, 29.97 fps (500 Mbps M-JPEG)
1920 x 1080p at 59.94 fps (180 Mbps MOV)
1920 x 1080p at 23.98, 24, 29.97 fps (90 Mbps MOV)
1920 x 1080p at 59.94 fps (60 Mbps MOV)
1920 x 1080p at 23.98, 24, 29.97 fps (30 Mbps MOV)
1280 x 720p at 120 fps (160 Mbps MOV)
1920 x 1080p at 59.94 fps (60 Mbps MP4)
1920 x 1080p at 23.98, 24, 29.97 fps (30 Mbps MP4)
1920 x 1080p at 29.97 fps (12 Mbps MP4) |
| Exposure Control |
Auto: Shutter Speed, Aperture, ISO
Manual: Shutter Speed, Aperture, ISO |
| ISO Sensitivity |
Auto, 100 – 32000 |
| Exposure Compensation |
-3 EV to +3 EV (in 1/3 or 1/2 EV steps) |
| Focus |
Auto
Manual
Continuous Auto |
| Max Video Clip Length |
4096 x 2160: 29 Minutes, 59 Seconds |
| Audio Recording |
Built-In Mic: With Video (Mono)
Optional External Mic: With Video (Stereo) |
| Battery |
1 x LP-E6N Rechargeable Lithium-Ion Battery Pack, 7.2 VDC, 1865 mAh |
| AC Power Adapter |
ACK-E6 (Optional) |
| Operating/Storage Temperature |
Operating
32 to 104°F (0 to 40°C)
Humidity: 0 – 85% |
| Dimensions (WxHxD) |
5.9 x 4.6 x 3.0″ / 150.7 x 116.4 x 75.9 mm |
| Weight |
1.760 lb / 800 g body only |
